hi there. anyone down to talk about silicon production (analog chips) in older processes? i'm talking to a fab and they're telling me the kind of design that i am talking to them about could result in a bunch of crosstalk, so i'm looking for ideas on how to mitigate that. the chip carries analog audio, so this is about capacitive coupling.

social

hi there. anyone down to talk about silicon production (analog chips) in older processes? i'm talking to a fab and they're telling me the kind of design that i am talking to them about could result in a bunch of crosstalk, so i'm looking for ideas on how to mitigate that. the chip carries analog audio, so this is about capacitive coupling.

I would just do a tapeout with Tiny Tapeout and see if it matches expectations

tiny tapeout is great, but my ultimate goal is to go into commercial production with a fab

1:02 a.m.

however, i resolved the crosstalk issue. i guess it was a translation problem between russian and english.

1:02 a.m.

they didn't mean to say it was going to create a bunch of crosstalk, they were telling me they had a solution which has low cross talk.

1:02 a.m.

they just didn't know how to say it

So I'm trying to work on the power gates for TT but hitting some DRC errors. In particular NP.12 I don't understand.

4:15 p.m.

NP.12 : Overlap with P-channel poly2 gate extension is forbidden within 0.32um of P-channel gate. Which I understand as, "NPlus can't overlap poly that's used by a pmos if that poly is closer than 0.32um to the actual gate zone"

4:16 p.m.

But then I get this from the DRC. ( Only COMP / Nplus / Poly shown ). And the Nplus doesn't overlat Poly at all ...
